Cummins QSB4.5-C110
Price excl. VAT
Print
INFO
Product group
Engines
Brand / model
Cummins QSB4.5-C110
Year of manufacture
2018
Condition
New/unused
Machine location
Jining, Shandong, China
Country
China
General grade
1
2
3
4
5
Mascus ID
BCC9CCF4
PRICING
Choose currency
DETAILS
Internal stock no.
QSB4.5-C110
Latest inspection
yes
Engine output
82 kW (111 hp)
Part ID
QSB4.5-C110
Full service history
Yes
Manufacturing / Serial number
QSB4.5-C110
Transport weight
380 kg
Transport dimensions (LxWxH)
900 x 750 x 1050 mm
RPM
2200
Emission level
Stage IIIB / Tier IV interim
Condition info/guarantee
ISO9001
Production country
China
Delivery terms
FCA, CPT, FOB, CFR, CIF, EXW
Other information
Cummins QSB4.5-C110 Diesel Engine for Vehicle
General Information of Cummins QSB4.5-C110 Diesel Engine for Construction
Engine Model QSB4.5-C110
Engine Type 4 Cylinders in Line
Displacement 4.5 L
Bore*Stroke(mm) 107 * 124
Compression Ratio 17.3:1
CPL Number 8754
Net Weight (with flywleel & alternator) 520 Kg
Overall Diemension(L*W*H) 1111mm*850mm*1100mm
Technical Specification of Cummins QSB4.5-C110Diesel Engine for Construction
Certification Euro III
Aspiration Turbocharged & Intercooled
Fuel System Wuxi weihu Pump
Electrical System(Starter Motor/Alternator) 12V/500A; 24V/250A
Lowest Starting Temp.(with/without auxiliary system) -12℃/-24℃
Engine Cooling Fluid Volume 7.0 L
Performance Data of Cummins QSB4.5-C110Diesel Engine for Construction
Rated Power/Speed 82kW/110HP @ 2200rpm
Max.Torque/Speed 502 N.m @ 1500 rpm
Fuel Consumption @ Rated Power 29 l/hr
Idel Speed 750 rpm
Max. Continuous Running Altitude 2000 m
