Sany SY 200 C Plus
Price excl. VAT
POA
Print
INFO
Product group
Crawler excavators
Brand / model
Sany SY 200 C Plus
Year of manufacture
2021
Country
China
General grade
1
2
3
4
5
Mascus ID
E7F790E1
DETAILS
Power type
Diesel
Latest inspection
2024-05-29
Undercarriage condition
good condition
Engine
Isuzu 4HK1-XDHAG-02-C3
Gross Weight
21,500 kg
Engine output
138 kW (188 hp)
Engine manufacturer
ISUZU
Bucket capacity
1 m3
Track width
600 mm
Transport dimensions (LxWxH)
9.68/2.8/3.44 m
Condition info/guarantee
good condition
Production country
China
Delivery terms
FCA, FAS, FOB, CFR, EXW
Certificates
EPA, CE, ANSI, AS, CSA
Other information
Main Performances:
·Travelling speed(km/h):3.4/5.4
·Swing speed(r/min):11
·Gradeability(%):70
·Digging force of bucket(kN):138
·Digging force of arm(kN):103
Working Range:
·The maximum excavating height(mm):9600
·The maximum unloading height(mm):6730
·The maximum excavating depth(mm):6600
·The maximum excavating radius(mm):10280
Boundary Dimension:
·Track length(mm):4160
·Wheel base of track(mm):2200
·The minimum rotation radius of the rear end(mm):2900
·The minimum ground clearance(mm):440
