INFO

Product group
Crawler excavators
Brand / model
CAT 323 D
Year of manufacture
2025
Hours of use
1,200 h
Country
China
General grade
1
2
3
4
5
Mascus ID
056ABCEC

PRICING

Choose currency

DETAILS

Internal stock no.
1
Power type
Diesel
Manufacturing / Serial number
1
Amount of previous owners
1
Latest inspection
2025-08-18
Undercarriage condition
good condition
Engine
Original
Gross Weight
24,500 kg
Engine output
151 kW (205 hp)
Engine manufacturer
Caterpillar
Registration number
1
Emission level
Stage V / Tier V
Bucket capacity
1.40 m3
Track width
600 mm
Top speed
5.70 km/h
Transport dimensions (LxWxH)
9530 x 2980 x 2960 mm
Original colour
Yellow
Dipper / stick length
2,900 mm
Condition info/guarantee
1 year
Production country
China
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Attachments
Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
Safety line rupture valve - boom/hoist
Safety line rupture valve - dipper/stick
Skeleton bucket
Rotating beacon
Extra equipment
Joystick control
Standard digging bucket
Other information
卡特彼勒新一代CAT®323 液压挖掘机 参数配置 规格 动力燃油 厂商合资/进口 铲斗反铲 吨位(吨)23 整机工作重量(kg)24500 铲斗容量(m³)1.4 动臂长度(mm)5700 斗杆长度(mm)2900 性能 回转速度(rpm)11.25 回转扭矩(Nm)82k 铲斗挖掘力(kN)140 斗杆挖掘力(kN)107 动力系统 发动机型号Cat® C7.1 额定功率(kw/rpm)151/2000 排量(L)7.01 缸径×行程(mm)105×135 排放标准国Ⅳ 液压系统 主泵最大流量(l/min)429 工作液压油路(Mpa)35 行走液压回路(Mpa)34.3 回转液压回路(Mpa )27.5 油类容量 燃油箱(L)345 液压油箱(L)115 液压系统(L)234 发动机油更换量(L)25 冷却液(L )25 主体尺寸 运输总长度(mm)9530 运输总宽度(mm)2980 运输总高度(mm)2960 履带板宽度(mm)600 履带轨距(mm)2380 最小离地间隙(mm )470 配重离地间隙(mm)1050 支重轮中心间距(mm)3650 后端回转半径(mm )2830 作业范围 最大挖掘半径(mm)9870 最大挖掘深度(mm)6730 最大挖掘高度(mm)9450 最大卸载高度(mm)6480 最大垂直挖掘深度(mm)5620

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
