INFO

Product group
Construction - Others
Brand / model
MORRISON VMC-4220B
Year of manufacture
2012
Condition
Used
Machine location
Langley, British Columbia
Country
Canada
Mascus ID
840B4C8B

PRICING

Choose currency

DETAILS

Internal stock no.
120259
Other information
Vertical Machining Center VMC-4220B Title: Vertical Machining Center VMC-4220B SKU: 120259 Model: VMC-4220B Year: 2012 Condition: Used S/N: 1200054 GeneralSpindle Taper:#40 Table Size:47" x 20" Speed:12000 rpm CNC:Yes ElectricalVoltage:230volts Phase:3-phase Amps:65amps Capacity X Axis Travel: 42" Y Axis Travel: 20" Z Axis Travel: 24" Table Loading Area: 47" x 20" Allowable Table Load: 1760 lb. Table T-Slot Spacing x Width: (5) - 15T x 100 inch Spindle Nose to Table Top: 3.3 - 23.3" Column to Spindle Center: 20.4" Standard Speed: 12,000 rpm Spindle Motor (30 min): 20 hp Spindle Torque (30 min): 142 ft-lb Automatic Tool Changer Number of Tools: 24 Tool Shank: Cat 40 (Big Plus) Max. Tool Diameter: 4" Max. Tool Length: 11.8" Max. Tool Weight: 15.4 lb Motion X and Y Axis Rapid Traverse Rate: 1,181 ipm Z Axis Rapid Traverse Rate: 1,181 ipm Cutting Feed Rate: 12 - 384 ipm Least Common Increment: 0.0001 in. Position Accuracy: +/- 0.0002 in. Repeatability: +/- 0.00008 in. Dimensions & Weights Floor Space: 123" x 98" Machine Weight: 15,400 lbShow more

Lenmark Industries Ltd

27576 51a Ave V4W 4A9 Langley British Columbia Canada
